Stryker Vertier
Stryker · Model Vertier
Extra-large casters for better mobility Simple connection options between sections Backlit hand control that is programmable Separate electronic control panel for backup Easy cleaning with sealed column Low minimum height Accommodating bariatric to pediatric patients with six section modular table top 8” bidirectional top slide X-Ray cassette slide for complete imaging access.
Key tips
- ·Never defeat or bypass a return-electrode monitoring (REM) alarm to finish a case - it's a direct burn risk.
- ·Verify OR table battery backup - a table that loses power mid-procedure is a real, documented incident type.
- ·Track surgical light lamp-hours rather than waiting for failure - a sudden failure mid-case is avoidable.
Typical Failure Modes
Compiled for this model from its own documentation and established engineering knowledge for this equipment class - not from a verified service record. Confirm against the manufacturer's service manual.
A powered function will not run
HighSymptoms: Height, tilt, Trendelenburg, back or leg section does not respond to the hand control / pendant.
Root cause: Hand control fault, an electro-hydraulic actuator, a control-board fault, or a low battery (mobile column).
Section drifts or will not hold
MediumSymptoms: Table settles under load after positioning.
Root cause: Hydraulic valve internal leak or an actuator backdrive.
Battery will not hold charge (mobile column)
MediumSymptoms: Short run time, table dies mid-procedure, battery alarm.
Root cause: Aged battery pack or a charger fault.
Hand control / pendant / cable fault
MediumSymptoms: Intermittent or dead hand control.
Root cause: Worn hand control or a damaged cable.
Table-top segment / rail / pad fault
LowSymptoms: Segments loose, accessory rails will not clamp, pads torn, radiolucent top damaged.
Root cause: Worn segment latches, rail clamps, or upholstery.
Serviceable Parts & Consumables
Serviceable items for this model, compiled from its documentation and engineering knowledge for this equipment class. Service class and relative cost are estimates, not manufacturer figures; no part numbers are given. Confirm intervals and pricing against the manufacturer.
Electro-hydraulic actuator
Class Major service partRel. cost $$$R&R Difficult
Hydraulic control valve block
Class Major service partRel. cost $$$R&R Difficult
Battery pack (mobile column)
Class Periodic replacementRel. cost $$R&R Fairly easy
Hand control / pendant
Class Periodic replacementRel. cost $$R&R Fairly easy
Table-top segment pads / rail clamps
Class Major service partRel. cost $$R&R Fairly easy
| Part | Service class | Relative cost | R&R difficulty |
|---|---|---|---|
| Electro-hydraulic actuator | Major service part | $$$ | Difficult |
| Hydraulic control valve block | Major service part | $$$ | Difficult |
| Battery pack (mobile column) | Periodic replacement | $$ | Fairly easy |
| Hand control / pendant | Periodic replacement | $$ | Fairly easy |
| Table-top segment pads / rail clamps | Major service part | $$ | Fairly easy |
Relative cost: $ lowest · $$$$ highest service-part cost for this equipment class. Not a price.
PM Checklist
Preventive-maintenance tasks typical of this equipment class. Perform to the manufacturer's procedure and your facility's policy - this is general reference, not a schedule for this specific unit.
- ·Pre-case functional check
- ·Electrosurgical return-electrode cable inspection
- ·Table hydraulic / mechanical inspection
- ·Annual electrical safety test and full PM
Troubleshooting Approach
A starting sequence for this model, compiled from its documentation and engineering knowledge for this equipment class. Follow the manufacturer's service documentation for the actual procedure.
Symptom: A powered movement will not run (height / tilt / Trendelenburg / back / leg)
- Confirm the table is on mains or the mobile-column battery is charged, and no lock-out is set.
- Operate the function and listen for the electro-hydraulic pump / actuator.
- Substitute a known-good hand control / pendant.
- Check the control cable and connectors for damage.
- Replace the actuator, the hydraulic valve or the control board as isolated, then load-test.
Symptom: A section drifts down / will not hold position under load
- Note how fast it settles and under what load.
- Check the hydraulic control valve for internal leak-by and the actuator for backdrive.
- Bleed and top up the hydraulic system per the manual.
- Rebuild or replace the leaking valve / actuator.
- Confirm the section holds at several positions under the rated load.
Symptom: Battery will not hold charge (mobile column)
- Charge fully and check the charger.
- Run a battery test if supported.
- Replace the battery pack.
- Confirm a full set of movements on battery after replacement.
- Inspect the charge socket and cable.
Symptom: Hand control / pendant intermittent or dead
- Flex the cable along its length and at both ends while operating.
- Inspect the connector for bent pins or moisture.
- Substitute a known-good pendant.
- Replace the pendant or its cable.
- Confirm every function from the replacement.
Typical Location
Where this class of equipment is typically deployed - general reference, not this unit's own placement record.
- Operating rooms
- Procedure rooms
- Interventional suites
Documents & Manuals
Safety & Recalls
Synced live from the FDA openFDA API.
- RECALL
In certain positions, product is susceptible to fluid instrusion which could possibly result in short circuit or unsolicited movement.
- RECALL
Potential for health care provider/hospital staff member to sustain injury to fingers or hands when removing/handling the headrest component of the VERTIER Surgical Table.
- RECALL
Surgical tables were produced using an unapproved tilt frame bushing.
- RECALL
Hydraulic lines responsible for tilting the surgical table have the potential to be severed when articulating table to its lowest position, possibly resulting in the unexpected and rapid movement of the table.
