Sonomed Escalon PacScan Plus
Sonomed Escalon · Model PacScan Plus
A-Scan Manual or automatic capture (cataract, dense cataract, aphakic, silicone oil, and pseudophakic modes) Auto calculation of axial length, anterior chamber depth, lens thickness, and vitreous, with axial length average and standard deviation provided for up to 10 scans per exam Standard IOL formulas: Binkhorst, Regression-II, Theoretic/T, Holladay, Hoffer-Q, and Haigis Post-refractive IOL formulas include Latkany Myopic Regression, Latkany Hyperopic, and Aramberri Double-K Easily review each scan, delete outlying scans, and add new scans Customizable tissue velocities of each structure Pachymeter Automatic measurement algorithm senses when probe is properly aligned Average and standard deviation computed for each reading (each reading consists of 64 individual measurements) Can measure central and peripheral cornea thickness; multiple corneal maps with graphical display Measurement range from 125 to 1000 microns enabling measurement of cornel flap Built-in probe sensitivity test and calibration confirmation
